Samsung washing machine error codes solutions & pdf

Samsung washer UR, UE or UB code

Cause

UR error code in Samsung washers is caused by unbalanced laundry. Very less and excessive laundry both causes the UR code in washing machine. Heavy washing items such as blanket, pillow, large towel can cause weight shift during the spin cycle.

Solution

There may be few reasons when a Samsung washer shows UR error code on the display. Now you try these given below solutions to troubleshoot the problem.

• Redistribute the laundry load in the washer.
• Check the type of laundry inside the washer.
• Make sure that laundry load balanced.
• Remove some laundry items to balance the load.
• Add some cloths if you have very less clothes.
• Removing some cloths from washer can also fix the issue if you have so many cloths inside the machine.
• Spread the heavy items load like large towel, pillow, blanket evenly inside the washer.

Note: To fix this type of error codes you may need to contact Samsung support or book an appointment to fix it.

Samsung washer Sud code

Sud error in some machine can be seen like “Sud” or “SUdS” depending on the model of the machine. Sometimes people also misread it as 5ud but actually it is Sud.

Cause

Sud error code comes on washer display due to the formation of the heavy foam. You should reduce the quantity of detergent used to prevent the formation of excess foam in the machine which causes Sud error code.

Solution

There may be few reasons when a Samsung washer shows UR error code on the display. Now you try these given below solutions to troubleshoot the problem.

Error Sud in reality is not a fault. Washing machine usually cure this problem on its own, however if it doesn’t resolve automatically then you will need to run either an “Eco drum clean” cycle (some models) or a 90°C cotton cycle with no detergent or washing load.

• Use adequate amount of detergent while washing.
• Prevent excessive formation of the foam.
• In most of cases it automatically resolves.
• Remove the excessive foam.

Samsung washer 4C or 4E code

Error codes 4C and 4E are same. In older machine you can find error code 4c and in newer machines it is replaced by 4E. Reason and solution for both error codes are same.

Cause

The only main reason of 4E error code is water blockage or deficiency in Samsung washing machine. And water blockage can occur due to the following reasons:

• No water supply in tab connected to the washing machine.
• Water tap connected to washing machine not opened properly.
• Water supply hose blocked due to sand or other obstructions.
• Kinked water supply hose can cause restrictions to the flow of water.
• Very less water flowing through hose due to limited amount of water supply.

Solution

Troubleshooting Samsung washing machine 4E code is very easy and simple. As we have already discussed that this issue occurs due to stoppage in water supply in washing machine.

We can check the following things to troubleshoot 4C error in Samsung washing machine:

• Make sure that adequate water supply is available in your tap.
• Washing machine is connected to the tap via water supply hose.
• Check that water tap connected to the washing machine is open to full.
• Check for the kinks or bents in the water hose connected to the machine and remove bents and kinks if available.
• Now check for any blockage in the water hose mesh filter.

Note: To fix this type of error codes you may need to contact Samsung support or book an appointment to fix it.

Samsung washer 5C or 5E code

Error codes 5e and 5E are the same. In older machines, you can find error code 5C and in newer machines, it is replaced by 5E. The reason and solution for both error codes are the same.

Cause

The only main reason of 5E error code is blockage of water in drainage system in Samsung washing machine. And water blockage can occur due to the following reasons:

• Incorrect drain hose installation to the washing machine.
• Bent or blockage in drain hose.
• Debris filter clogged/blocked with lints or dirt/dust.
• Drain pump fault.
• Foreign materials in the drain pump.
• Fault in the Main PCB.

Solution

Troubleshooting Samsung washing machine 5E code is very easy and simple. As we have already discussed that this issue occurs due to a stoppage in water draining system in the washing machine.

We can check the following things to troubleshoot 5C error in Samsung washing machine:

• Incorrect drain hose installation is the most common reason for drain issues, and service is rarely required.
• Route the drain hose properly.
• Clean the debris filter clogged/blocked with lint or dirt/dust.
• Straighten the drain hose all the way to the drain system. Also, ensure that it’s not clogged.
• Check and clear the drain pump motor if restrained by foreign material.
• Check the connections are correct and fix the wires connections if there is any wire is disconnected.

Note: To fix this type of error code you may need to contact Samsung support or book an appointment to fix it.

Samsung washer DC, DE & ED code

Error codes dE, dE1, Ed, dC, DC1, and DC occur in Samsung washers if there is some problem with the washing machine door.

Cause

The only main reason for dE, dE1, Ed, dC, DC1, and DC error codes is a problem with the door switch or main PCB in Samsung washing machine. And water blockage can occur due to the following reasons:

• Door switch fault.
• Fault in the Main PCB.

Solution

Troubleshooting Samsung washing machines for dE, dE1, Ed, dC, DC1, and DC code is very easy and simple. As we have already discussed that this issue occurs due to a stoppage in the water draining system in the washing machine.

We can check the following things to troubleshoot these errors in Samsung washing machine:

• Close the door if it is opened.
• Make sure that laundry is not caught in the door, remove the cloth if it is caught in the door.
• Now check the door switch. If faulty, replace it.
• Check the main PBA door sensing circuit. If faulty, replace it
• Also check the drain Pump wire connection.

Note: To fix this type of error code you may need to contact Samsung support or book an appointment to fix it.

Samsung washer LE, E9, 11E & LC code

Error codes LE, LE1, E9, 11E, LC and LC1 occur if there is some water leakage-related problem with the washing machine door.

Cause

The only main reason for LE, LE1, E9, 11E, LC and LC1 error codes is a problem in water leakage problem in Samsung washing machine. And water blockage can occur due to the following reasons:

• Water leakage is the main reason for these codes.
• Foreign material in the DV case.
• The fault of a hose or incorrect part engagement in the product.

Solution

Troubleshooting Samsung washing machine dc & de code is very easy and simple. As we have already discussed that this issue occurs due to a stoppage in the water draining system in the washing machine.

We can check the following things to troubleshoot dE, dE1, Ed, dC, DC1, and DC error in Samsung washing machine:

• Try to fix for water leakage if any on the base, Hose, Valve and Tub connections.
• Check the drain motor operation. Replace it if it does not operate normally.

Note: To fix this type of error code you may need to contact Samsung support or book an appointment to fix it.

Samsung washer NF code

Error codes NF in washing machines represent the No Fill.

Cause

The only main reason for NF error code is a problem in water leakage problem in the Samsung washing machine. And water blockage can occur due to the following reasons:

• Water hose is clogged.
• The washer is not plugged in and powered on.
• The debris filter is clogged.

Solution

Troubleshooting Samsung washing machine NF code is very easy and simple. We can check the following things to troubleshoot the NF error in the Samsung washing machine:

• Check the water pressure.
• Ensure that the door is tightly closed.
• Clean the mesh filters of the water hose.
• Ensure the washer is plugged in and powered on. If it does not power on, check the fuse and reset the circuit breaker.
• Make sure the source water tap is completely turned on.
• Check that there are no kinks in the water hose connected to the washing machine and that it is not clogged.

Note: To fix this type of error code you may need to contact Samsung support or book an appointment to fix it.

Samsung washer CC code

Error codes CC in washing machines is related to cooling.

Cause

The only main reason for CC error code is related to cooling in the Samsung washing machine. And it can occur due to the following reasons:

• Washing Temperature sensor fault.
• Description of PL hazard prevention.

Solution

Troubleshooting Samsung washing machine CC code is very easy and simple. We can check the following things to troubleshoot the CC error in the Samsung washing machine:

• Check the water temperature is not more than 50˚C in draining and allow it to cool down or mix some normal water to decrease the temp.
• If the water temperature is normal, this error is due to a temperature sensor fault. In this case, replace the washing heater and be careful to prevent water leakage.

Note: To fix this type of error code you may need to contact Samsung support or book an appointment to fix it.

Samsung washing machine 1E, E7 & 1C code

Error codes 1E, E7 & 1C in washing machines are related to the water level sensor.

Cause

The only main reason for 1E, E7 & 1C error codes is a problem with the water level sensor in the Samsung washing machine. And it can occur due to the following reasons:

• The water hose is clogged with foreign material.
• Fault in water level sensor.
• The water hose part for the water level sensor is folded.
• The water level sensor terminal has incorrect connections.

Solution

Troubleshooting Samsung washing machine 1E, E7 & 1C code is very easy and simple. We can check the following things to troubleshoot 1E, E7 & 1C error in Samsung washing machine:

• Check and fix the water level sensor terminal connections.
• Check the material code to ensure the correct water level sensor is used.
• If the water level sensor is faulty, replace it.

Note: To fix this type of error code you may need to contact Samsung support or book an appointment to fix it.
